NL128102AC29-17

Panel Brand: NLTPanel
Model: NL128102AC29-17
Panel Size: 19.0"
Panel Type: a-Si TFT-LCD, LCM
Resolution: 1280(RGB)×1024 , SXGA
Pixel Format: RGB Vertical Stripe
Display Area: 376.32(W)×301.056(H) mm
Bezel Opening: 380.32(W)×305.06(H) mm
Outline Size: 396(W)×324(H) ×18.5(D) mm
Surface: Antiglare, Hard coating (2H)
Brightness: 800 cd/m² (Typ.)
Contrast Ratio: 1000:1 (Typ.) (TM)
Viewing Angle: 88/88/88/88 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode: UA-SFT, Normally Black, Transmissive
Best View on:Symmetry
Response Time: 14/11 (Typ.)(Tr+Td)
Display Colors: 16.7M   100% sRGB
Lamp Type: WLED , 94K hours , With LED Driver
Frequency:60Hz
Touch Screen: Without
Panel Weight: 2.10/2.31Kgs (Typ./Max.)
Application: Industrial
Signal Interface: LVDS (2 ch, 8-bit) , 30 pins , Connector
Input Voltage: 5.0V (Typ.)
Environment: Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C

NL128102AC29-17 inverter, NL128102AC29-17 power supply, NL128102AC29-17 electronic board, NL128102AC29-17 VGA board, NL128102AC29-17 touchscreen available.

Shunlongwei Inspected every NL128102AC29-17 before Ship, All NL128102AC29-17 with 6 months warranty.

NL128102BC29-01B

Brand: NEC
Model: NL128102BC29-01B
Diagonal Size: 19.0 inch
Type: a-Si TFT-LCD , LCM
Pixel Format 1280(RGB)×1024   [SXGA]
Configuration: RGB Vertical Stripe
Active Area: 376.32(H)×301.056(V) mm
Outline Dim.: 404.2(H)×330(V) ×25.55(D) mm
Bezel Area: 380.3(H)×305.1(V) mm
Treatment: Antiglare, Hard coating (2H)
Luminance: 280 cd/m² (Typ.)
Contrast Ratio: 450:1 (Typ.) (TM)
View Direction: Symmetry
Response Time: 10/10 (Typ.)(Tr/Td)
Viewing Angle: 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode: SA-SFT, Normally Black, Transmissive
Support Color: 16.7M   72% NTSC
Light Source: CCFL  [6 pcs] , W/O Driver
Weight: 2.90/3.10Kgs (Typ./Max.)
Designed For: Desktop Monitor
Frame Rate: 60Hz
Touch Panel: Without
Interface Type: 30 pins   LVDS (2 ch, 8-bit) , Connector
Power Supply: 5.0V (Typ.)
Environment: Operating Temperature: 0 ~ 55 °C ; Storage Temperature: -20 ~ 60 °C

NL128102BC29-01B inverter, NL128102BC29-01B power supply, NL128102BC29-01B electronic board, NL128102BC29-01B VGA board, NL128102BC29-01B touchscreen available.

Shunlongwei Inspected every NL128102BC29-01B before Ship, All NL128102BC29-01B with 6 months warranty.

climbing helmet

POK TYRONE LTD offers a wide range of helmets that feature high levels of robustness, quality and comfort. A small selection of helmets meets the needs of every kind of Cliambers, from basic utility helmets for construction and industrial activities to more complex designs that meet the specific demands of rope access and tree climbing specialists. Climbing Helmet

We are Climbing Helmet Manufacturer, Wholesale Climbing. Email: sales@oemhelmet.com Web : www.oemhelmet.com

TECHNOLOGY: In-mold technology; PC shell; EPS liner; Seamless Design; EVA clean pads; A-06 High Lock Control System; ITW buckle;Chinpad;

FEATURES: 11 Air vents; Reflectors for better visibility; Strap Dividers for easy handling; ITW buckle with chinpad; Weight 300 gram;

AVAILABLE SIZES: M -L(56-58 cm); L-XL(59-62 cm)

NL128102BC29-10

Manufacturer: NEC
Model Name: NL128102BC29-10

Screen Size: 19.0 inch
Screen Type: LCM ,   a-Si TFT-LCD

Pixel Number: 1280(RGB)×1024   (SXGA)
Arrangement: RGB Vertical Stripe

Active Area(mm): 376.32 × 301.056 (H×V)
Outline(mm) :404.2 × 330 × 24.1 (H×V×D)

Treatment: Antiglare, Hard coating (2H)

Luminance: 300 cd/m² (Typ.)
Contrast Ratio: 800 : 1 (Typ.) (TM)

Viewing Angle: 88/88/88/88 (Typ.)(CR≥10) Left / Right / Up / Down
Response: 10/10 (Typ.)(Tr/Td) ms

Good View at: Symmetry
Work Mode: UA-SFT, Normally Black, Transmissive

Color Depth: 16.7M   72% NTSC
Backlight: 6 pcs CCFL , 50K hours , No Driver

Mass: 2.60/2.75Kgs (Typ./Max.)
Used for: Industrial  Medical Imaging

Refresh Rate: 60Hz
Touchscreen: Without

Signal Type: LVDS (2 ch, 8-bit) , Connector , 30 pins

Voltage Supply: 5.0V (Typ.)

Max. Ratings: Storage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 55 °C

NL128102BC29-10C inverter, NL128102BC29-10C power supply, NL128102BC29-10C electronic board, NL128102BC29-10C VGA board, NL128102BC29-10C touchscreen available.

Shunlongwei Inspected every NL128102BC29-10C before Ship, All NL128102BC29-10C with 6 months warranty.

NL160120AC27-20

Manufacturer: NEC
Model Name: NL160120AC27-20

Screen Size: 21.3 inch
Screen Type: LCM,   a-Si TFT-LCD

Pixel Number: 1600(RGB)×1200   (UXGA)
Arrangement: RGB Vertical Stripe

Active Area(mm): 432 × 324 (H×V)
Outline(mm): 457 × 350 × 37 (H×V×D)

Bezel Area(mm): 438.2 × 330.0 (H×V)
Treatment: Antiglare, Hard coating (2H)

Luminance: 950 cd/m² (Typ.)
Contrast Ratio: 800 : 1 (Typ.) (TM)

Viewing Angle: 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down
Response:14/11 (Typ.)(Tr/Td) ms

Good View at: Symmetry
Work Mode: SA-SFT, Normally Black, Transmissive

Color Depth: 16.7M   72% NTSC
Backlight: 16 pcs CCFL , With Inverter

Mass: 2.90/3.10Kgs (Typ./Max.)
Used for: Medical Imaging

Refresh Rate: 60Hz

Touchscreen: Without

Signal Type: LVDS (2 ch, 8-bit) , Connector , 40 pins

Voltage Supply: 12.0V (Typ.)

Max. Ratings: Storage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 55 °C

NL160120AC27-20 inverter, NL160120AC27-20 power supply, NL160120AC27-20 electronic board, NL160120AC27-20 VGA board, NL160120AC27-20 touchscreen available.

Shunlongwei Inspected every NL160120AC27-20 before Ship, All NL160120AC27-20 with 6 months warranty.

NL192120AC25-02

Panel Brand: NEC
Panel Model: NL192120AC25-02

Panel Size: 22.5"
Panel Type: a-Si TFT-LCD, LCM

Resolution: 1920(RGB)×1200 , WUXGA
Pixel Format: RGB Vertical Stripe

Display Area: 483.84(W)×302.4(H) mm
Bezel Opening: 489.2(W)×306.6(H) mm

Outline Size: 542(W)×362(H) mm
Surface: Antiglare, Hard coating (2H)

Brightness: 420 cd/m² (Typ.)
Contrast Ratio: 800:1 (Typ.) (TM)

Viewing Angle: 88/88/88/88 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode: UA-SFT, Normally Black, Transmissive

Best View on: Symmetry
Response Time: 6/6 (Typ.)(Tr/Td)

Display Colors: 1.07B   97% Adobe RGB
Lamp Type: 12 pcs CCFL , 45K hours , With Inverter

Frequency: 120Hz

Touch Screen:Without

Panel Weight: 3.45/3.65Kgs (Typ./Max.)
Application: Desktop Monitor

Signal Interface: LVDS (4 ch, 10-bit) , 104 pins , Connector

Input Voltage: 12.0V (Typ.)

Environment: Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

NL192120AC25-02 inverter, NL192120AC25-02 power supply, NL192120AC25-02 electronic board, NL192120AC25-02 VGA board, NL192120AC25-02 touchscreen available.

Shunlongwei Inspected every NL192120AC25-02 before Ship, All NL192120AC25-02 with 6 months warranty.

NL204153AC21-17

Manufacturer: NEC
Model Name: NL204153AC21-17

Screen Size: 21.3 inch
Screen Type: LCM,   a-Si TFT-LCD

Pixel Number: 2048(RGB)×1536   (QXGA)
Arrangement: RGB Vertical Stripe

Active Area(mm): 433.152 × 324.864 (H×V)
Outline(mm): 457 × 350 × 23 (H×V×D)

Bezel Area(mm): 438.2 × 330.0 (H×V)
Treatment: Antiglare, Hard coating (2H)

Luminance: 800 cd/m² (Typ.)
Contrast Ratio: 1400 : 1 (Typ.) (TM)

Viewing Angle: 88/88/88/88 (Typ.)(CR≥10) Left / Right / Up / Down
Response: 20/20 (Typ.)(Tr/Td) ms

Good View at: Symmetry
Work Mode: UA-SFT, Normally Black, Transmissive

Color Depth: 1.07B   72% NTSC
Backlight: WLED , 70K hours , With LED Driver

Mass: 2.70/2.98Kgs (Typ./Max.)
Used for:Medical Imaging

Refresh Rate: 60Hz
Touchscreen: Without

Signal Type: LVDS (4 ch, 10-bit) , Connector , 104 pins

Voltage Supply: 12.0V (Typ.)

Max. Ratings: Storage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 60 °C

NL204153AC21-17 inverter, NL204153AC21-17 power supply, NL204153AC21-17 electronic board, NL204153AC21-17 VGA board, NL204153AC21-17 touchscreen available.

Shunlongwei Inspected every NL204153AC21-17 before Ship, All NL204153AC21-17 with 6 months warranty.

TM043NDH02

TM043NDH02

Panel Brand: TIANMA
Panel Model: TM043NDH02

Panel Size: 4.3"
Panel Type: a-Si TFT-LCD, LCM

Resolution: 480(RGB)×272 , WQVGA
Pixel Format: RGB Vertical Stripe

Display Area: 95.04(W)×53.856(H) mm
Bezel Opening: 99.6(W)×56.7(H) mm

Outline Size: 105.5(W)×67.2(H) ×3.2(D) mm
Surface: Antiglare, Hard coating (3H)

Brightness: 300 cd/m² (Typ.)
Contrast Ratio: 500:1 (Typ.) (TM)

Viewing Angle: 70/70/70/50 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode: TN, Normally White, Transmissive

Best View on: 6 o’clock
Response Time: 20 (Typ.)(Tr+Td)

Display Colors: 16.7M 50% NTSC
Lamp Type: 5S2P WLED , 20K hours , Without Driver

Frequency: 60Hz

Touch Screen: Without

Panel WeightL: 44.1g
Application: Portable Navigation MP3 PMP

Signal Interface: Parallel RGB (1 ch, 8-bit) , 40 pins , FPC

Input Voltage: 3.3V (Typ.)

Environment: Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C

TM043NDH02 inverter, TM043NDH02 power supply, TM043NDH02 electronic board, TM043NDH02 VGA board, TM043NDH02 touchscreen available.

Shunlongwei Inspected every TM043NDH02 before Ship, All TM043NDH02 with 6 months warranty.

TM047NBH01

Brand: TIANMA
Model: TM047NBH01

Diagonal Size: 4.7 inch
Type: a-Si TFT-LCD , LCM

Pixel Format: 480(RGB)×272   [WQVGA]
Configuration: RGB Vertical Stripe

Active Area: 103.68(H)×58.752(V) mm
Outline Dim.: 114.3(H)×72.5(V) mm

Treatment: Antiglare, Hard coating (3H)

Luminance: 280 cd/m² (Typ.)
Contrast Ratio: 500:1 (Typ.) (TM)

View Direction: 12 o'clock
Response Time: 25 (Typ.)(Tr+Td)

Viewing Angle: 70/70/60/70 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode: TN, Normally White, Transmissive

Support Color: 16.7M   50% NTSC
Light Source: WLED  [5S2P] , 20K hours , W/O Driver

Weight: 76.5g (Typ.)
Designed For: Portable Navigation  MP3 PMP

Frame Rate: 60Hz

Touch Panel: 4-wire Resistive Touch

Interface Type: 45 pins   Parallel RGB (1 ch, 8-bit) + SPI , FPC

Power Supply: 3.3V (Typ.)

Environment: Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C

TM047NBH01 inverter, TM047NBH01 power supply, TM047NBH01 electronic board, TM047NBH01 VGA board, TM047NBH01 touchscreen available.

Shunlongwei Inspected every TM047NBH01 before Ship, All TM047NBH01 with 6 months warranty.

TM150TCS02

Manufacturer: AVIC
Model Name: TM150TCS02

Screen Size: 15.0 inch
Screen Type: LCM ,   a-Si TFT-LCD

Pixel Number: 1024(RGB)×768   (XGA)
Arrangement: RGB Vertical Stripe

Active Area(mm): 304.128 × 228.096 (H×V)
Outline(mm): 326.5 × 253.5 × 12 (H×V×D)

Bezel Area(mm): 307.4 × 231.3 (H×V)
Treatment: Antiglare, Hard coating (3H)

Luminance: 250 (Typ.)(cd/m²)
Contrast Ratio: 500 : 1 (Typ.) (TM)

Viewing Angle: 80/80/80/80 (Typ.)(CR≥10)
Work Mode: TN, Normally White, Transmissive

Response: 4/14 (Typ.)(Tr/Td) ms

Color Depth: 16.7M   50% NTSC
Backlight: 2 pcs CCFL , 50K hours , No Driver

Mass: 0.97/1.05Kgs (Typ./Max.)
Used for :Industrial

Refresh Rate: 60Hz
Touchscreen: Without

Signal Type:LVDS (1 ch, 8-bit) , Connector , 20 pins

Voltage Supply:3.3V (Typ.)

Max. Ratings:Storage Temp.: -20 ~ 80 °C    Operating Temp.: -20 ~ 70 °C



TM150TCS02 inverter, TM150TCS02 power supply, TM150TCS02 electronic board, TM150TCS02 VGA board, TM150TCS02 touchscreen available.

Shunlongwei Inspected every TM150TCS02 before Ship, All TM150TCS02 with 6 months warranty.

TX48D21VM0CAA

Brand: HITACHI
Model: TX48D21VM0CAA  Diagonal Size: 19.0 inch
Type: a-Si TFT-LCD, LCMPixel Format: 1680(RGB)×1050   [WSXGA+]
Configuration: RGB Vertical StripeActive Area: 409.5(H)×255.94(V) mm
Outline Dim.: 444(H)×300(V) mmTreatment:AntiglareLuminance:300 cd/m² (Typ.)
Contrast Ratio: 900:1 (Typ.) (TM)    View Direction: SymmetryViewing Angle: 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode: S-IPS, Normally Black, TransmissiveSupport Color: 16.7M
Light Source: CCFL  [6 pcs]Weight:  2.90Kgs
Designed For: Medical ImagingFrame Rate:  60HzInterface Type:   LVDS (2 ch, 8-bit)Power Supply: 12.0V (Typ.)
TX48D21VM0CAA inverter, TX48D21VM0CAA power supply, TX48D21VM0CAA electronic board, TX48D21VM0CAA VGA board, TX48D21VM0CAA touchscreen available.


Shunlongwei Inspected every TX48D21VM0CAA before Ship, All TX48D21VM0CAA with 6 months warranty.

TX54D32VC0CAA

Panel Brand: HITACHI
Panel Model: TX54D32VC0CAA

Panel Size: 21.3"
Panel Type: a-Si TFT-LCD, LCM

Resolution: 1600(RGB)×1200 , UXGA
Pixel Format: RGB Vertical Stripe

Display Area: 432(W)×324(H) mm
Outline Size: 460.6(W)×362(H) mm
Surface: Antiglare

Brightness: 750 cd/m² (Typ.)
Contrast Ratio: 1100:1 (Typ.) (TM)

Viewing Angle: 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode: S-IPS, Normally Black, Transmissive

Best View on: Symmetry

Display Colors: 16.7M
Lamp Type: 12 pcs CCFL

Panel Weight:  2.50Kgs
Application: Industrial  Medical Imaging  Outdoor High Brightness

Signal Interface:  LVDS (2 ch, 8-bit)

Input Voltage: 12.0V (Typ.)

TX54D32VC0CAA inverter, TX54D32VC0CAA power supply, TX54D32VC0CAA electronic board, TX54D32VC0CAA VGA board, TX54D32VC0CAA touchscreen available.

Shunlongwei Inspected every TX54D32VC0CAA before Ship, All TX54D32VC0CAA with 6 months warranty.

ZJ080NA-08A

Panel Brand: Chimei Innolux
Panel Model: ZJ080NA-08A

Panel Size: 8.0"
Panel Type: a-Si TFT-LCD, LCM

Resolution: 1024(RGB)×600 , WSVGA
Pixel Format: RGB Vertical Stripe

Display Area: 176.64(W)×99.36(H) mm
Bezel Opening: 179.84(W)×103.16(H) mm

Outline Size: 192.8(W)×116.9(H) ×6.7(D) mm

Brightness: 500 cd/m² (Typ.)
Contrast Ratio: 700:1 (Typ.) (TM)

Viewing Angle: 75/75/70/75 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode: TN, Normally White, Transmissive

Best View on: 6 o'clock
Response Time: 10/20 (Typ.)(Tr/Td)

Display Colors: 16.7M   70% NTSC
Lamp Type: WLED , 20K hours , Without Driver

Frequency: 60Hz
Touch Screen: Without

Panel Weight: 0.23Kgs (Typ.)
Application: Automotive Display

Signal Interface:  LVDS (1 ch, 8-bit) , 40 pins , FPC

Input Voltage: 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VHL)

Environment: Operating Temp.: -20 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C

ZJ080NA-08A inverter, ZJ080NA-08A power supply, ZJ080NA-08A electronic board, ZJ080NA-08A VGA board, ZJ080NA-08A touchscreen available.

Shunlongwei Inspected every ZJ080NA-08A before Ship, All ZJ080NA-08A with 6 months warranty.

LQ057Q3DC12

Panel Brand : SHARP

Panel Model : LQ057Q3DC12

Panel Type : a-Si TFT-LCD , Panel

Panel Size : 5.7 inch

Resolution : 320(RGB)×240 , QVGA

Display Mode : TN, Normally White, Transmissive

Active Area : 115.2×86.4 mm

Outline : 144×104.6×12.3 mm

Surface : Hard coating (3H)

Brightness : 500 cd/m² (Typ.)

Contrast Ratio : 350:1 (Typ.)

Display Colors : 262K   (6-bit)

Response Time : 8/21 (Typ.)(Tr/Td)

Viewing Angle : 65/65/65/40 (Typ.)(CR≥5) (L/R/U/D)

Lamp Type : 1 pcs CCFL

Signal Interface : Parallel RGB (1 ch, 6-bit)

Input Voltage : 3.3V (Typ.)(VCC)

RoHS : Yes



LQ057Q3DC12 inverter, LQ057Q3DC12 power supply, LQ057Q3DC12 electronic board, LQ057Q3DC12 VGA board, LQ057Q3DC12 touchscreen available.

Shunlongwei Inspected every LQ057Q3DC12 before Ship, All LQ057Q3DC12 with 6 months warranty.

LQ080V3DG01

Panel Brand : SHARP

Panel Model : LQ080V3DG01

Panel Type : a-Si TFT-LCD , Panel

Panel Size : 8.0 inch

Resolution : 640(RGB)×480 , VGA

Display Mode : TN, Normally White, Transmissive

Active Area : 162.24×121.68 mm

Outline : 183×141 mm

Surface : Antiglare, Antireflection

Brightness : 380 cd/m² (Typ.)

Contrast Ratio : 250:1 (Typ.)

Display Colors : 262K   (6-bit)

Response Time : 30/50 (Typ.)(Tr/Td)

Viewing Angle : 65/65/65/55 (Typ.)(CR≥10) (L/R/U/D)

Lamp Type : 1 pcs CCFL

Signal Interface : Parallel RGB (1 ch, 6-bit)

Input Voltage : 3.3/5.0V (Typ.)(VCC)



LQ080V3DG01 inverter, LQ080V3DG01 power supply, LQ080V3DG01 electronic board, LQ080V3DG01 VGA board, LQ080V3DG01 touchscreen available.

Shunlongwei Inspected every LQ080V3DG01 before Ship, All LQ080V3DG01 with 6 months warranty.
